V30-35ZMU Very Narrow Aisle
V30-35ZMU Very Narrow Aisle
V30-35ZMU Very Narrow Aisle

Very Narrow Aisle Man Up Turret Truck

UNRIVALED VERSATILITY TO FIT YOUR APPLICATION

Models
V30-35ZMU
Capacity
3000-3500lbs

The Hyster Very Narrow Aisle (VNA) lift trucks help optimize storage capacity and efficiently retrieve pallets in high intensity operations.

  • Decreased downtime
  • Low cost of operation
  • Built for comfort
  • Enhanced productivity
  • Unrivaled versatility
Industry Sector

‐ Wholesale Distribution
‐ Warehouse & 3PL
‐ Building Material
‐ Home Centers
‐ General MFG
‐ Retail & E-Commerce (DC/fulfillment)
‐ Furniture & Furnishings
‐ Health & Pharma
‐ Auto Parts Distribution

Start a quote

Interested in more information on this lift truck? Our solutions team is available to discuss your specific application and how this product can meet your needs.

Start a quote

The space saver

Expansive features for very narrow aisles.

Decreased downtime

The V30-35ZMU series is designed for reduced service needs, so you can keep things moving. When regular maintenance is necessary, it can be done quickly.

  • Key components are accessed via a one-piece steel motor compartment cover that opens 180º.
  • CANBUS communication system allows single point diagnostic access of all truck components.
  • Fixed position of the traction motor prevents twisting and stretching of cable connections.
  • Bolt-on mast bearings allow easy inspection and replacement.
  • Attachment bearings are easily accessed and adjustable.
  • Tilt-out hydraulic control valve allows easy access to components.
Low cost of operation

Get an edge on the competition with the V30-35ZMU series of very narrow aisle turret trucks that cost less to operate and help increase your productivity.

  • AC traction, hoist and steering motors have no brushes to check or replace.
  • Extended service intervals on major components
  • Several key truck functions can be operated simultaneously without a decrease in power for enhanced efficiency and productivity.
  • Superior energy efficiency
  • MOSFET AC Controllers
  • Patent-pending hydraulic pressure compensation system
  • Continuous vehicle system monitoring
  • Thermal management
  • CANBUS communication system reduces wiring and electrical connections.
Built for comfort

The advanced ergonomic design of the V30-35ZMU series allows the operator to maintain maximum comfort and productivity throughout an entire shift.

  • Armrests and joysticks are fully adjustable for standing or sitting operators.
  • Standard dome light, work lights and cabin fan optimize operator comfort and productivity.
  • With three-way adjustment of the forward-mounted console, operators can easily reach controls.
  • Superior forward and rear visibility is provided by an open main mast design and a large rear window.
  • Low step height eases entry and exit.
  • Operator foot sensors, located under the floorboard, are larger for easy activation.
  • Seat can swivel between 0º to 20º.
  • Optional forward-mounted console is completely adjustable.
Enhanced productivity

The V30-35ZMU series gives you the power to get more done.

  • Exclusive HySense Advance feature monitors lift height and load weight to provide maximum truck performance
  • Rigid tri-form or quad-form mast design
  • Multi-tasking design allows simultaneous operation of all truck functions.
  • Automatic synchronized traverse and rotation of attachment
  • Automatic forks forward/centering function
  • Automatic regenerative braking
  • Automatic regenerative cab lowering
  • Optional pre-height selector automatically reduces lift speed when the turret head approaches a pre-defined height.
Unrivaled versatility

The Hyster V30-35ZMU trucks deliver unrivaled versatility. A host of options allow you to choose the truck your application requires:

  • Five chassis choices
  • Three operator compartment configurations
  • Standard open cab design for easy order picking access
  • 48 or 72 volt

Operators can program truck performance for their preferred working style to boost productivity. Adjustable parameters include:

  • Acceleration
  • Travel speed
  • Lift /lower speeds
  • Regenerative braking force
  • Lift limits
  • Operator password access
  • Optional load wheel brakes
  • Optional freezer conditioning
  • Optional freezer cab with heater
  • Optional fork tilt and positioning
  • Optional shuttle table
Model Load Capacity Lift Height Platform Height Battery Capacity Voltage Weight
W30ZMU L 3000lbs 550 423 48V / 1240Ah 15475
W35ZMU L 3500lbs 579.5 563 72V / 1240Ah 17426
W35ZMU S 3500lbs 579.5 536 72V / 775Ah 15744
W35ZMU M 3500lbs 579.5 563 72V / 930Ah 16907
